Turbolader 5700198 75700198 334640 53279706615 53279886615 53279706615 5327-988-6615 5327-970-6615 5700197 LIEBHERR D9406TIE 12,88 L K27.2-3266MNBAA11.12GYATB KKK BORGWARNER
Onderdeelnummers:
53279886615, 53279706615, 53279886615, 53279706615, 5327-988-6615, 5327-970-6615, 5700197, 5700122 , 5700123, 5700 197, K27.2-3266MNBAA11.12GYATB, 5327 988 6615, 53279886615, LIEBHERR 5700198, LIEBHERR 5700123, LIEBHERR 5700122, LIEBHERR 5700197, LIEBHERR 5700123A, LIEBHERR 5700122A, LIEBHERR 5700198A, LIEBHERR 5700197A, 5327-990-6616, 5327-980-6612, 53279886611, 5327-970-6615, 5327-988-6612, 5327-988-6616, 53279706611, 5327-980-6615, 53279806612, 53279706615, 5327-970-6611, 5327-990-6612, 53279886615, 5327-970-6616, 53279886612, 53279906615, 53279806615, 53279906616, 53279906611, 53279906612, 5327-980-6611, 53279806616, 53279886616, 53279706616, 5327-990-6611, 5327-988-6615, 5327-988-6611, 5327-980-6616, 53279706612, 53279806611, 5327-970-6612, 5327-990-6615
Motor:
R964B / R964 / R964 Li / D9406TIE
| Part Number | 53279886615 |
| Previous Version | 5327-988-6615, 5327 988 6615 |
| OE number | 5700197 |
| Year | 1995-10 |
| Description | Earth Moving |
| Manufacturer Part Number | 53279706615, 5327-970-6615 |
| CHRA | 53277100118 (5327-710-0118) |
| Turbo Model | K27.2-3266MNBAA11.12GYATB |
| Engine | D9406TIE |
| Displacement | 12.88L, 12880 ccm |
| KW | 266/362 |
| RPM Max | 1900 |
| Fuel | Diesel |
| Angle α (compressor housing) | 220° |
| Angle β (turbine housing) | 0° |
| Bearing Housing | 53271500018 (53271500011)(Oil Cooled) |
| Turbine Wheel | 53271205075 (53271202111, 53271202121, 53271202126, 53271205006, 53271205007, 53271205011, 53271205012, 53271205020, 5327-1205025, 53271205041, 53271205079)(Ind. 69.95 mm, Exd. 62.63 mm, Trm 10.56, 12 Blades)(1301027437, 1100030038 |
| Comp. Wheel | 53271232312 (53271232204)(Ind. 53.3 mm, Exd. 81. mm, Trm 3.3, 7+7 Blades, Superback) |
| Back plate | 53271516710 |
| Heat shield Number | 53271652004 (53271652006, 53271652007, 53271652017) |
| Repair Kit | 53277110053 (53277110023, 53277110030, 53277110055, 53277110056, 53267110050, 53267110047, 53267110048)(1301027760) |
| Turbine Housing | 53271016314 |
| Compressor Cover | 53271014923 (53271014806) |
| Turbine Housing AR | 11 |
| Gasket (turbine inlet) | 409039-0001 (409039-0000, 210190-0000, 132044, 312617, 2405022) |
| Gasket (turbine outlet) | 210245 |
| Gasket (oil outlet) | 210060 (409267-0003, 409267-0002, 210060-0000, 51914, 148062, 311585, 860105) |
| Gasket oil inlet | 210023 (409036-0000, 210023-0000, 55739, 147837, 215234, 52231586500) |
| Gasket Kit | |
| NOTE | Intercooler |
| Manufacturer | Borg Warner - 3K - Schwitzer |
| Tightening torques, plays, clearances, wastegate adjustment | |||||||||||||||||||||||||
| for T/C 5327 988 6616 | |||||||||||||||||||||||||
| Note: ./. | |||||||||||||||||||||||||
|
|||||||||||||||||||||||||
|
|||||||||||||||||||||||||
|
|||||||||||||||||||||||||
|
|||||||||||||||||||||||||
|
|||||||||||||||||||||||||
