Turbocharger 40397014, 039700, 4039701, H4090048, 409004800 4090048, 4039701H, 4039700, 4039701 Holset Cummins Marine QSB
Suitable for:
Various vehicles - see part numbers for compatibility
Specifications:
Engine codes:
See product specifications
Part numbers:
4039701, 4039700, 4039701H4090048, 409004800, CUMMINS 4090048, 4039701H, 4039700, 4039701
| Part Number |
4039701 |
| Previous Part Number |
4039700, 4039701H |
| OE number |
4090048, 409004800 |
| Description |
Marine Cummins B series |
| CHRA |
4031387 |
| Turbo Model |
HX40, HX40M, HX40-B85J71GT/B76T81FJ13PF |
| Engine |
ISB |
| Displacement |
6 Cylinders |
| Fuel |
Diesel |
| KW |
420 HP |
| Engine Manufacturer |
Cummins |
| Bearing Housing |
4041454 (Oil Cooled) |
| Turbine Wheel |
3536624 (3525687)(Ind. 75.92 mm, Exd. 61.6 mm, Trm 12.29, 12 Blades) |
| Comp. Wheel |
4035879 (3599016, 4043377, 3596097)(Ind. 60. mm, Exd. 86. mm, Trm 5.86, 7+7 Blades, Superback)(1154351400, 1200016234) |
| Back plate |
3530923 (1800016009) |
| Heat shield Number |
3519302 (2030016031) |
| Repair Kit |
3575169 (1153035750, 5000020021) |
| Turbine Housing (Water Cooled) |
3599050 (4039717) |
| Compressor Cover |
4039694 |
| Gasket Kit |
4032577 |
| Manufacturer |
HOLSET |
